AC Motor Run Capacitor Suitable For Air Conditioner

FOB Price:

Get Latest Price

Min.Order Quantity:

200 Piece

Supply Ability:

100000 Piece per Day

Port:

ANY PORT IN CHINA

Place of Origin:

CHINA

Payment Terms:

L/C, D/P, T/T, Western Union, MoneyGram, Credit Card, PayPal, Cash

Brand:

RETEKOOL

Products Model:

CBB65 CBB60

Products Details
Company Profile

Quick Details

Brand Name: RETEKOOL

Model Number: CBB65 CBB60

Place of Origin: CHINA

Packaging & Delivery

Packaging Details: PACKED IN SEAWORTHY PACKAGES
Delivery Detail: WITHIN 30-40 DAYS AFTER RECEIVING YOUR DOWN PAYMENT

Specifications

370/450V Cbb65 AC Motor Run Capacitor Suitable For Air Conditioner

Metal case,plastic insulation. insulation oil impregnation, with inner pressure protection device, safe and reliable; small volume,light weight,high insulation resistance,high withstand voltage,low dissipationfactor, good self-healing, stable performance and etc.

Specifications

CBB65 air conditioner compressor run capacitor
Used widely in motors,air conditioner ,water pump
sample available

Climatic

category

Rate voltage

Testing voltage

T-T

Testing voltage

T-C

Capacitance

tolerance

Dissipation

factor

-25/+70/21

-40/+85/21

370/440VAC

1.75Un/5S

(2Un/5S)

2000V.AC/5s

±5%

(±10%)

≤0.002

(100Hz)

Applications:

Run starting in household electric appliances air conditioner,

refrigerator which demand 50/60Hz AC power supply Have

safe protection constrution.

General specificaiton for capacitor:

1. General description:
Broadly applied to running of single-phase AC motors at 50Hz(60Hz)frequency for washedrs and high efficiency compressors of refrigerators etc.

2.Features:

The capacitor takes heavy-edge metallized, AI/Zn pp film or web-like fuse metallized pp film as dieledtrie, its components are assembled in flame-retardant ABS or PBT ey lindrical crust, impregnated with flame-retatdant epoxy resin,It has high reliability and stability.

3.Technical parameter

Standard:GB3667-1997,same as IEC60252:193

Climate type:40/70/21, 40/85/21

Capacitance tolerance: ±5%

Dielectric dissipation factor: tg&≤0.002(50Hz~100Hz)

Life expectancy:3000h(ClassC)or10000h(ClassB)

4.Service condition

Altitude:≤2000m

Residual voltage in application:Less than 10% of rated voltage
Allowed maximum voltage: Less than 1.1 times of rated voltage
Permissible maximum current: Less than 1.3 times of rated current

JINAN RETEK INDUSTRIES INC (JINAN RETEKOOL INC) is a professional manufacturer in China , specializing in refrigeration condenser , evaporator and copper fitler driers.

Our company devoted to innovation and development of refrigeration industry all the time . We take the lead in adopting the new design concept for wire tube condenser that can replace copper condenser .Due to new situation of low carbon and environmental protection , we develop most compact,efficient and highest resistance of salt spray test CO2 refrigerant wire tube condenser.

From year 2012 , our new products roll bond evaporators and fin evaporators ( aluminium evaporator ) are supplied to many different countries' refrigerator factory .These products are eco-friendly , high efficiency and energy conservation .

Our company have advanced manufacture equipment , strong technical team and first class management system . We have more than 30 national patents products & technology . We have been awarded the ISO9001:2008 international quality system certificate , ISO14000, RoHS certificate and UL certificate .

Now our products are mainly supplied to refrigerator/ freezer /water dispenser factories in more than 80 countries , include USA , Italy , Korea ,Russia ,Pakistan,India ,Mexico ,Indonesia ,UK......We also welcome customers all over the world to visit our company and set up business relationship for further development
